Epistar Creative Led Display Screen

Product Categories
Shenzhen Xing Guang Cai Technology Co., Limited
Contact Now

Epistar Creative Led Display Screen

  • 1
  • 2

Brand Name : XGC

Model Number : P2

Certification : CE ,FCC, ROSH CCC

Place of Origin : Shenzhen,China

MOQ : 1PCS/ 1 ㎡

Price : USD880--USD1800 /㎡

Payment Terms : T/T、, Western Union、L/C、, D/A、, D/P, MoneyGram

Supply Ability : 5000㎡ per month.

Delivery Time : 7-15 days

Packaging Details : Plywood case、flight case

Product name : LED Panel Indoor P2

Display function : Video,picture,Indoor,text,graphics

Warranty : 2~3 Years

Application : Live Events,stage ,meeting room,gym,etc

Cabinet size : 512*512*75mm

Weight : 8kg/pcs

Power supply : 5V40A 200W AC110~220V

Refresh rate : 3840Hz/s

Contact Now

Front service LED panel Indoor P2 Fixed Epistar Creative Led Display Screen

Advantage:

1. Excellent effect: Using dynamic scanning technology, the picture is stable, no noise, the image effect is clear, the animation effect is vivid and diverse, and the video effect is smooth and realistic;
2. Rich in content: can display text, graphics, images, animation, video information;
3. The cabinet customization: the cabinet supports customized size;
4. Excellent viewing angle: both horizontal and vertical have a large viewing angle, which is suitable for environments with wide horizontal distribution and large height difference;
5. High reliability: using distributed scanning technology and modular design technology, reliability and stability are higher;
6. Quality assurance: the use of imported luminescent materials, high-quality IC chips, noise-free high-power power supply; tensile and shockproof, 11 years of long life;
7. Easy maintenance: modular design, easy installation and maintenance.

Technical Parameter for P2 INDOOR FIXED TYPE LED DISPLAY
Module Specifications
1 Pixel Pitch 2mm

2 Led Type SMD1515/2020
3 Pixel configuration 1R1G1B
4 Module Size 256x128mm
5 Module Resolution 128x64pixels
6 LED Chip Epistar
7 LED brand Hongsheng/Forest/ Kinglight/Nationstar/
Cabinet Specification
1 Cabinet Size 512x512mm or customized
2 Cabinet Resolution 256x256 pixels
3 Module Qty. 2x4pcs
4 Power Supply 5V40A 200W/ 5V60A 300W
6 Cabinet Materials Die casting aluminum/ iron
7 Signal flight socket 1set
8 Power flight socket 1set
Screen Parameters
1 Pixel density 25000dots/㎡
2 Screen Resolution according to screen size
3 Cabinet Qty. according to screen size
4 Brightness ≥1200 CD/sqm
5 Refresh rate ≥1920Hz/s
6 Scanning Mode 1/32 scan
7 Viewing Angle H:140°;V:140°
8 Viewing Distance ≥2m
9 Gray Level 16 Bit
10 Power Input AC110~240V
11 Power Comsuption Max: 800W/㎡ Average:200W/㎡
12 MTBF--hours >10,000 hours
13 Life--hours ≥100,000 hours
14 IP Grade IP40/IP30
15 Operating Temperature -35℃~ 65℃
16 Storage Humidity 10℃~70℃RH
17 Control Syetem Colorlight/Nova/Linsn
18 Operating System Windows98/me/2000 /NT/XP
19 Power Supply 5V40A 200W/5V60A 300W
20 Maintance Access Back service/Front service
21 Video processor Colorlight/Novastar/Linsn/VDWALL/RGBLIN/KYstar
21 Control mode computer /USB/WIFI/4G

HS code: 8528591090

Epistar Creative Led Display Screen

Epistar Creative Led Display Screen

Our Services

1) Guidance service: We can guide on line if customers have questions about the installation and usage.

For large project, we provide your engineer a week free training, or if customer could bear the relevant cost,

our engineer can go to customer’s country for on-site guidance.

2) Warranty period: 2~3 years after shipment.

3) Maintenance principles: response in time, solve problems as soon as possible and ensure the use.

4) Maintenance terms: In the Maintenance period, free of all maintenance charges.

Under normal use and storage, our company will be responsible for the equipments.

If there is any failure in product quality, our company will maintain and change the components for free. After Maintenance period, only charge the material costs fees free of manual work fees.

We would like to know more details before offering you the best quotation.

1. What is screen size and what cabinet you prefer.

2. What is the best viewing distance with your project.

3. For fixed or rental installation.

4. When do you need to get goods and is it urgent or not.

5. Any special requests such as video processor, hanging bar, flight case for package.
